GAI Series

Multifunctional high precision scales, suitable for laboratory, industrial use, jewelry and pawn shops and cash for gold shops.

Available Capacity(g): 420, 620, 2200, 4200, 6200.

Available on Indent Order.

• Main Features

  • Backlit LCD display with 7 digits 16.5mm high.
  • Waterproof membrane keypad, with 5 keys.
  • Construction: bearing structure in die cast aluminium, ABS case.
  • Weight detection through tuning fork system.
  • Stainless steel plate, size:
  • - GAI420N and GAI620N models Ø 118mm
  • - GAI2200N, GAI4200N, GAI6200N models 180x160mm.
  • Winscreen (on GAI420N and GAI620N models), level, adjustable feet.
  • Power supply: standard fitte with 230 Vac power adapter.
  • Operating temperature +5°C...+35°C, non-condensing relative humidity 80%.
  • RS232/c port for connection to PC, 3590EGT series indicator or printer.
  • Internal calibration (except GAI6200N)

• Functions

  • counting
  • % weight
  • conversion units of measure
  • Standard versions, not approved: g, kg, ct, oz, lb, ozt, dwt
  • zeroing
  • zero tracking
  • semi-automatic tare
  • digital calibration

• Available Models

  Part Number	Class	Pan Size (mm)	Capacities
  GAI420N	II	Ø 118 mm	420g x 0.001g
  GAI620N	I	Ø 118 mm	620g x 0.001g
  GAI2200N	II	180 x 160 mm	2200g x 0.01g
  GAI4200N	II	180 x 160 mm	4200g x 0.01g
  GAI6200N	I	180 x 160 mm	6200g x 0.01g

• Documents

  Dini GAI Brochure

  500 Kb
